Description
Easytrim Grafter 100gsm High performance roofing membrane
High performance roofing membrane that is vapour permeable, water resistant and airtight. They allow vapour to escape from the inside whilst repelling rainwater from the outside, helping to minimise condensation in the roof space. The membranes are available with or without integrated overlap tap.
Suitable for:
- Warm, cold and hybrid roof applications
- Scottish sarking boards
- Timber & metal framed constructions
- Fully supported or unsupported installations
- Tiled or slate pitch roofs
Features and Benefits:
- Excellent tensile strength / tear resistance
- V Stable for 3 months
- Superior 3-layer bond system
- Printed cutting grid minimising waste
- Available with or without integrated overlap tape
- Integrated tape allows for faster installation
- Integrated tape membranes are suitable for use in all five wind zones
Quality Standards:
- BBA certified for warm and cold roof applications BBA 10/4753
- Complies to all Wind Zones 1-5
- Conforms to BS 5534.2014 Annex A
- Type LR Underlay to BS 5250
| Colour | Grey Felt with Red Printed Grid |
| Material | Polypropylene |
| BBA Certified | Warm and Cold Roof Applications BBA 10/4753 |
| Conforms to | BS 5534.2014 Annex A : Slating & Tiling for Pitched Roofs & Vertical Tiling, BS 5250: For Roof Space Ventilation (Management and Moisture in Buildings), All NHBC requirements |
| Weight | 100gsm |
| Fire Rating | E |
| Wind Zone Suitability | Zones 1-2 |
| Width | 1m |
| Length | 50m |
| Coverage | 50m² |
| Packed Quantity | 1 |
| Pallet Quantity | 60 |
| Product Code | EASYTRIMGRAFT1 |
